Grinding fixture ZS32/110-2
The botek grinding fixture ZS is designed for low volume production re-sharpening of single flute gundrills.
The fixture may be installed on a botek grinding machine MS-01, or a standard tool grinding machine.
The desired angles are set on the grinding fixture using graduated scales.
The gundrill is inserted into the clamping unit and a vee-shaped jaw holds the gundrill securely in the flute.
When choosing a grinding fixture, please consider the minimum flute length and gundrill diameter of the tools you wish to regrind.
Scope of delivery:
Clamping range Ø: 2.0 – 32.0 mm
Minimum flute length of tool: 110 mm
