Système BTA

Type 70A

botek Type 70 – L’alternative au Système Coro Drill 800 de Sandvik-Se monte sur tous les tubes de forage.

wdt_ID	Type	Ø	Numéro de commande
1	Type 70A	25,00 mm	501001689
2	Type 70A	26,00 mm	501002372
3	Type 70A	28,00 mm	501002369
4	Type 70A	30,00 mm	501002366
5	Type 70A	32,00 mm	501001912
6	Type 70A	35,00 mm	501002374
7	Type 70A	38,00 mm	501002375
8	Type 70A	45,00 mm	501002380

Corps de forage Type 70A/B

vis incluses, sans pièces de rechange

wdt_ID	Type	Ø	Numéro de commande
1	Type 70A	25.00 - 45.00 mm	501000000A
2	Type 70B	25.00 - 45.00 mm	501000000B

wdt_ID	Typ	Ø von - bis	Artikelnummer
1	Type 43B	60,00 – 149,99 mm	512000100
2	Type 43B	149,00 – 368,99 mm	512000101
3	Type 43A	60,00 – 149,99 mm	512000102
4	Type 43A	149,00 – 368,99 mm	512000103
5	Type 43F	199,00 – 368,99 mm	512000104
6	Type 64	28,71 - 74,99 mm	512000105
7	Type 70A	25,00 - 65,00 mm	512000106
8	Type 61	15,65 – 17,95 mm	512000107
9	Type 61	18,00 – 36,20 mm	512000108
10	Type 14	15,60- 65,00 mm	512000109
11	Type 12	28,50 - 74,99 mm	512000110
12	Type 70B	25,00 - 65,00 mm	512000111
13	Type 11	14,55 – 17,95 mm	512000112
14	Type 11	18,00 – 36,99 mm	512000113
15	Type 20	14,51 - 36,99 mm	512000114
18	Type 13B	28,50 - 74,99 mm	512000117
19	Type 13A	28,5 - 74,99 mm	512000118
20	Type 34	44,00 - 353,99 mm	512000119
21	Type 54	47,00 - 353,99 mm	512000120
22	Type 35B	61,00 - 498,99 mm	512000121
23	Type 35A	61,00 – 223,99 mm	512000122
24	Type 35F	224,00 - 498,99 mm	512000123
29	Type 38	20,00 - 222,99 mm	512000128
30	Type 58	20,00 - 222,99 mm	512000129
31	Type 28	55,00 – 197,99 mm	512000130
32	Type 48	55,00 - 197,99 mm	512000131
33	Type 48	198,00 - 412,99 mm	512000132
35	Type 49	jusqu'à Ø 60,00 mm	512000134

Tube de forage Type 25

avec filetage extérieur à 1 filet

BD1	BD2	DCONWS	LCONWS	wdt_ID	Pas de vis	Numéro d’article
12,0 mm	8,0 mm	11,5 mm	23,3 mm	1	6 mm	25-9310-OAL
13,0 mm	8,5 mm	11,8 mm	23,3 mm	2	6 mm	25-9410-OAL
13,0 mm	8,5 mm	12,4 mm	23,3 mm	3	6 mm	25-9510-OAL
14,0 mm	9,0 mm	12,7 mm	23,3 mm	4	6 mm	25-9610-OAL
14,0 mm	9,0 mm	13,4 mm	23,3 mm	5	6 mm	25-9710-OAL
15,0 mm	10,0 mm	13,7 mm	23,3 mm	6	6 mm	25-9810-OAL
15,0 mm	10,0 mm	14,4 mm	23,3 mm	7	6 mm	25-9910-OAL
16,5 mm	11,0 mm	15,5 mm	23,0 mm	8	6 mm	25-0110-OAL
18,0 mm	12,0 mm	16,5 mm	26,0 mm	9	10 mm	25-0210-OAL
20,0 mm	13,0 mm	19,0 mm	26,0 mm	10	10 mm	25-0310-OAL
22,0 mm	14,0 mm	20,0 mm	26,0 mm	11	10 mm	25-0410-OAL
24,0 mm	15,5 mm	22,0 mm	26,0 mm	12	10 mm	25-0510-OAL
26,0 mm	17,0 mm	24,0 mm	26,0 mm	13	10 mm	25-0610-OAL
28,0 mm	18,5 mm	26,0 mm	26,0 mm	14	10 mm	25-0710-OAL
30,0 mm	20,0 mm	27,0 mm	41,0 mm	15	20 mm	25-0810-OAL
33,0 mm	23,0 mm	30,0 mm	41,0 mm	16	20 mm	25-0910-OAL
36,0 mm	25,5 mm	33,0 mm	41,0 mm	17	20 mm	25-1010-OAL
39,0 mm	28,0 mm	37,0 mm	41,0 mm	18	20 mm	25-1110-OAL
43,0 mm	31,0 mm	41,0 mm	41,0 mm	19	20 mm	25-1210-OAL
47,0 mm	35,0 mm	44,0 mm	41,0 mm	20	20 mm	25-1310-OAL
51,0 mm	39,0 mm	49,0 mm	41,0 mm	21	20 mm	25-1410-OAL
56,0 mm	43,0 mm	53,0 mm	41,0 mm	22	20 mm	25-1510-OAL
62,0 mm	48,0 mm	59,0 mm	41,0 mm	23	20 mm	25-1710-OAL
68,0 mm	53,0 mm	65,0 mm	71,0 mm	24	40 mm	25-1810-OAL
75,0 mm	59,0 mm	71,0 mm	71,0 mm	25	40 mm	25-1910-OAL
82,0 mm	66,0 mm	79,0 mm	71,0 mm	26	40 mm	25-2010-OAL
94,0 mm	78,0 mm	90,0 mm	71,0 mm	27	40 mm	25-2110-OAL
106,0 mm	88,0 mm	102,0 mm	71,0 mm	28	40 mm	25-2210-OAL
118,0 mm	94,0 mm	114,0 mm	71,0 mm	29	40 mm	25-2310-OAL
130,0 mm	104,0 mm	126,0 mm	71,0 mm	30	40 mm	25-2410-OAL
142,0 mm	116,0 mm	139,0 mm	71,0 mm	31	40 mm	25-2510-OAL
154,0 mm	128,0 mm	151,0 mm	86,0 mm	32	56 mm	25-2610-OAL
166,0 mm	136,0 mm	163,0 mm	86,0 mm	33	56 mm	25-2710-OAL
178,0 mm	145,0 mm	175,0 mm	86,0 mm	34	56 mm	25-2810-OAL
190,0 mm	154,0 mm	187,0 mm	86,0 mm	35	56 mm	25-2910-OAL
202,0 mm	166,0 mm	199,0 mm	86,0 mm	36	56 mm	25-3010-OAL
214,0 mm	178,0 mm	211,0 mm	86,0 mm	37	56 mm	25-3110-OAL
226,0 mm	190,0 mm	223,0 mm	86,0 mm	38	56 mm	25-3210-OAL
238,0 mm	202,0 mm	235,0 mm	86,0 mm	39	56 mm	25-3310-OAL
250,0 mm	214,0 mm	247,0 mm	121,0 mm	40	56 mm	25-3410-OAL
262,0 mm	226,0 mm	259,0 mm	121,0 mm	41	56 mm	25-3510-OAL
274,0 mm	238,0 mm	271,0 mm	121,0 mm	42	56 mm	25-3610-OAL
286,0 mm	250,0 mm	283,0 mm	121,0 mm	43	56 mm	25-3710-OAL
298,0 mm	262,0 mm	295,0 mm	121,0 mm	44	56 mm	25-3810-OAL
310,0 mm	274,0 mm	307,0 mm	121,0 mm	45	56 mm	25-3910-OAL
322,0 mm	286,0 mm	319,0 mm	121,0 mm	46	56 mm	25-4010-OAL
334,0 mm	298,0 mm	331,0 mm	121,0 mm	47	56 mm	25-4110-OAL
346,0 mm	310,0 mm	343,0 mm	121,0 mm	48	56 mm	25-4210-OAL
